T20 EBIKE
Peak 1000W (rated 500W) torque 50 Nm, can climb 25 degree slope / Peak 1500W (rated 1000W) torque 60 Nm, can climb 27 degree slope
What Online Reviewers Say T20
The T20 ebike is favored by more and more customers, and many customers have posted their objective evaluations of the T20 on YouTube.
T20 Specifications
Performance
- Top Speed: Class 2/3, 28 Mph (45Km/h)
- Range: 40+miles (64km) in Class-2 throttle-only mode (pure electricity); 70+miles (113km) in Class-1 PAS (pedal assist)
- Motor: 48V Peak 1000W (Rated 500W) 50Nm/ Peak 1500W (Rated 1000W) 80Nm Brushless Rear Hub Motor
- Battery: 48V 20Ah Battery (Lithium 18650 Cells)
- Energy: 960Wh
- Front Suspension: 20" Shoulder Shock Absorbing, 80mm Travel
- Rear Suspension: 1800 Pounds, 180mm Travel, Hole spacing 180mm
- Brakes: Disc Brake, Equipped with 160mm Stainless Brake Disc / Oil Brake, Equipped with 180mm Stainless Brake Disc
- Tires: Chaoyang Sunny Road Tire 20"*4" IA-5189
- Throttle: Grip Twist Throttle
Electronics
- Charger: 48V3A Charger
- Charging Time: 3.5-8.0 Hours
- Display: Easy Read LCD Display
- Controller: 48V 22A
- Front Light: LED
- Rear Light: LED
- Pedal Assist: 5 Levels
- Sensors: Speed Sensor
Components
- Frame: Hydroformed Triple-Butted 6061-T6 Aluminium Alloy
- Pedal: Aluminum Alloy Pedal, with Reflect-light, Axis 9/16 x2
- Crank: 1/2 "*3/32"*46T 7-speed ED Tooth Plate
- Rear Derailleur: Shimano 7-Speed
- Chain: 7-speed Anti-rust, 1/2" * 3/32"
- Handlebars: Iron, Curved Handle, Matte Black 620L*Φ31.8*H: 30 High
Geometry
- Suitable Height: 5'7" - 6'8"
- Seat Height: 35.8" (91cm)
- Bike Height: 45.3" (115cm)
- Wheelbase: 43.3" (110cm)
- Handlebar Width: 25.6" (65cm)
- Bike Weight: ≥88lbs (with Battery) (≥40kg)
- Maximum Load: 330lbs (150kg)
- Safe Load: 265lbs (120kg)
- Overall Size: 70.9" * 25.6" *45.3" (180*65*115cm)
- Package Size: 54.3" * 11.8" * 30.7" (138*30*78cm)
T20 is fully equipped with Shimano seven-speed cassette, which allows you to drive smoothly and climb easily on steep roads.
There is a USB 1AH charging port under the T20 display, which is convenient for you to charge your mobile phone with low battery when riding outdoors, ensuring your safety.
The frame is made of fully customized hydraulically formed three-butted 6061-T6 aluminum alloy. It has been tested for more than 30,000 times and is durable and reliable.
The seat height is adjustable,suitable for people with aheight of 5.3-6.8 (ft).
Peak 1000W (rated 500W) with disc brake, 160mm stainless steel brake disc / Peak 1500W (rated 1000W) with dual piston oil brake, 180mm stainless steel brake disc
Both front and rear shock absorption, suspension travel 180MM，good resilience, so you are not afraid of any road.
T20 is fully equipped with Shimano seven-speed cassette, which allows you to drive smoothly and climb easily on steep roads.
There is a USB 1AH charging port under the T20 display, which is convenient for you to charge your mobile phone with low battery when riding outdoors, ensuring your safety.
The frame is made of fully customized hydraulically formed three-butted 6061-T6 aluminum alloy. It has been tested for more than 30,000 times and is durable and reliable.
The seat height is adjustable,suitable for people with aheight of 5.3-6.8 (ft).
Peak 1000W (rated 500W) with disc brake, 160mm stainless steel brake disc / Peak 1500W (rated 1000W) with dual piston oil brake, 180mm stainless steel brake disc
Both front and rear shock absorption, suspension travel 180MM，good resilience, so you are not afraid of any road.
T20 was launched in 2019, focusing on light off-road and commuting electric bikes. The original model is equipped with a peak 1000W (rated 500W) high-speed brushless motor, a 22AH controller, and a torque of 50Nm. T20 launched an upgraded version in 2024, with a peak 1500W (rated 1000W) high-speed brushless motor, a 28AH controller, and a torque of 80Nm. The off-road performance is greatly improved.
T20 provides 960Wh (20AH) high-quality 18650 lithium battery with a range of up to 70 miles (113KM) and a max speed of 28MPH (45KM/H). It is legal and complies with Class 2 and Class 3 modes.
The appearance of T20 has won the German Red Dot Award and has an appearance patent. The unique design makes you a fashionable person!
Customers And T20
Support
Manual
VIN Number
The VIN number (Serial number) of the T20 ebike is in the middle of the front fork of each T20 (please note that the VIN number of the T20 is unique and cannot be repeated)
Package
T20 Ebike*1/Fender*2/Charger*1/Manual*1/Tool Bag*1
The VIN number (Serial number) of the T20 ebike is in the middle of the front fork of each T20 (please note that the VIN number of the T20 is unique and cannot be repeated)
T20 Ebike*1/Fender*2/Charger*1/Manual*1/Tool Bag*1
